Key Features
- Complete Cambo WTSA-870 tilt-swing lens panel with integrated Rodenstock HR Digaron-W 70mm f/5.6 lens
- Designed for Cambo WRS and WDS technical camera systems
- Compatible with Phase One XT (no electronic data transfer)
- Designed for medium format digital backs with sensor-activated electronic shutters
- Precision helical focusing mount with minimum focus distance of 0.9 m (3 ft)
- Integrated ±5° tilt and ±5° swing movements with independent geared controls
- Positive zero-stop mechanism for fast, accurate alignment
- Large 100mm image circle at f/11 for generous camera movements
- High-resolution optics optimized for digital sensors with 5µm pixel pitch
- Manual aperture range from f/5.6 to f/45
- Standard 58mm (E58) front filter thread
- Ideal for architecture, landscape, product, and fine art photography with precise Scheimpflug control.
Product Description
The Cambo WTSA-870 Tilt-Swing Lens Panel with Rodenstock HR Digaron-W 70mm f/5.6 Lens is a premium technical camera solution designed for photographers requiring precise focus-plane control and exceptional image quality. Built for the Cambo WRS and WDS camera systems, this lens panel combines Rodenstock's renowned HR Digaron-W 70mm optics with Cambo's precision-engineered Tilt-Swing (T/S) mechanism, making it ideal for architectural, landscape, commercial, and product photography.
The integrated Rodenstock HR Digaron-W 70mm f/5.6 lens delivers outstanding sharpness, high contrast, and excellent color fidelity across a 100mm image circle, optimized for modern high-resolution medium format digital backs. Designed specifically for digital capture, the lens effectively minimizes chromatic aberration, astigmatism, and field curvature while providing outstanding edge-to-edge performance. It performs optimally between f/5.6 and f/8, making it an excellent choice for demanding professional applications.
The WTSA-870 distinguishes itself with an integrated geared tilt and swing mechanism, allowing ±5° of tilt and ±5° of swing. Both movements can be adjusted independently or simultaneously, enabling precise application of the Scheimpflug principle for expanded depth of field or selective focus effects. A positive zero-stop ensures quick return to perfectly parallel alignment for repeatable shooting.
Mounted in Cambo's precision helical focusing mount, the lens focuses from infinity down to approximately 0.9 meters (3 feet). Because this is an Aperture Body configuration, exposures are made using the electronic shutter built into compatible digital backs, eliminating the need for a mechanical leaf shutter while maintaining maximum optical performance. The WTSA-870 is also compatible with the Phase One XT platform (without electronic communication).
Specifications
| Specification | Details |
|---|---|
| Product Name | Cambo WTSA-870 Tilt-Swing Lens Panel with Rodenstock HR Digaron-W 70mm f/5.6 Lens |
| Manufacturer Part Number | 99162870 |
| Focal Length | 70mm |
| Maximum Aperture | f/5.6 |
| Minimum Aperture | f/45 |
| Lens Type | HR Wide-Angle Technical Camera Lens |
| Optical Optimization | High-Resolution Digital Sensors (5µm Pixel Pitch) |
| Recommended Working Aperture | f/5.6 – f/8 |
| Image Circle | 100mm at f/11 |
| Image Angle | 70° |
| Minimum Focus Distance | 0.9 m (3 ft) |
| Focus System | Integrated Helical Focus Mount |
| Tilt Movement | ±5° |
| Swing Movement | ±5° |
| Movement Control | Independent Geared Knobs with Zero Stop |
| Filter Thread | E58 (58mm) |
| Aperture Control | Manual |
| Shutter | None (Uses Electronic Shutter in Digital Back) |
| Compatible Cameras | Cambo WRS, Cambo WDS, Phase One XT |
| Compatible Digital Backs | Digital Backs with Electronic Shutter |
| Recommended Applications | Architecture, Landscape, Product Photography, Fine Art, Commercial Photography, Perspective Control |
What's Included
- Cambo WTSA-870 Tilt-Swing Lens Panel
- Rodenstock HR Digaron-W 70mm f/5.6 Lens
- Integrated Helical Focusing Mount
- Front Lens Cap
- Rear Lens Cap
- Limited Manufacturer Warranty
