Key Features
- Professional Linos inspec.X L 105mm Float industrial macro lens
- Floating element optical design for exceptional image quality across a 0.3x to 3.0x magnification range
- Ideal for film digitization, macro photography, industrial inspection, and precision reproduction
- Bright f/5.6 maximum aperture with manual adjustment to f/22
- Large 82mm image circle for technical camera systems
- Optimized for image sensors with 5µm pixel size
- Geared focus and aperture rings for automated and precision imaging workflows
- Full-metal housing for industrial durability
- Requires Cambo WHF-4 or ACB-V lens plate (sold separately)
- M46 front filter thread
- Working distance of 100–420mm
- Low distortion of less than 0.4% across the imaging field
Product Description
The Cambo Linos inspec.X L 105mm f/5.6 Float Lens is a premium industrial macro lens engineered for demanding reproduction, archival digitization, scientific imaging, and industrial inspection. Unlike fixed-magnification versions of the inspec.X L series, this model incorporates floating element optics, allowing it to maintain exceptional optical performance throughout a wide 0.3x to 3.0x magnification range with a single lens.
Its advanced optical design delivers outstanding sharpness, high contrast, excellent color fidelity, and minimal distortion across the frame. The generous 82mm image circle makes it suitable for technical cameras and large-format imaging systems, while the lens is optimized for modern high-resolution sensors with 5-micron pixels, ensuring exceptional detail for archival reproduction and precision imaging.
Designed with professional workflows in mind, the lens features geared magnification and aperture rings, making it well suited for automated inspection systems, motorized copy stands, and industrial imaging environments. The rugged full-metal housing ensures long-term reliability in demanding production settings.
The lens mounts via the optional Cambo WHF-4 or ACB-V lens plate, providing seamless integration with Cambo reproduction and technical camera systems. Whether digitizing film, photographing scientific specimens, or performing industrial metrology, the Cambo Linos inspec.X L 105mm Float delivers uncompromising optical performance.
Specifications
| Specification | Details |
|---|---|
| Product Name | Cambo Linos inspec.X L 105mm f/5.6 Float |
| Manufacturer Part Number | 999105001 |
| Focal Length | 105mm |
| Maximum Aperture | f/5.6 |
| Minimum Aperture | f/22 |
| Magnification Range | 0.3x – 3.0x |
| Lens Type | Industrial Macro / Reproduction Lens |
| Optical Design | Floating Element Optics |
| Image Circle | 82mm |
| Working Distance | 100–420mm |
| Optimized Sensor Pixel Size | 5µm |
| Spectral Range | 400–750nm |
| Distortion | <0.4% |
| Lens Mount | Requires Cambo WHF-4 or ACB-V Lens Plate |
| Compatible Lens Plates | Cambo WHF-4, Cambo ACB-V |
| Filter Thread | M46 |
| Focus | Manual (Geared Ring) |
| Aperture Control | Manual (Geared Ring) |
| Housing | Precision Full-Metal Construction |
| Weight | 440 g (15.5 oz) |
| Recommended Applications | Film Digitization, Industrial Inspection, Macro Photography, Scientific Imaging, Museum Digitization, Archival Reproduction, Precision Metrology |
What's Included
- Cambo Linos inspec.X L 105mm f/5.6 Float Lens
- Limited Manufacturer Warranty
Create unlimited custom tabs and add any product detail, module, widget, design or HTML. Also possible to create custom tab layout using layout builder
Cambo Linos inspec.X L 105mm f/5.6 Float Industrial Macro Lens for Reproduction & Film Digitization
